SLANA

SLANA Round Double

EW1N/EW1S/EW1M Ø90/Ø125/Ø160 Double heads wall light
Architectural yet expressive, SLANA Round Double introduces a refined decorative dimension to functional lighting. Designed for wall mounting, it delivers dual-direction illumination that defines vertical surfaces while contributing balanced ambient light to expansive public spaces. Meticulous construction and disciplined optics ensure both visual comfort and structural clarity in high-volume interiors.

Specifications

Model
Comment

Power

(W)

LEDs

(Quantity)

Max Lumens

(lm)

Control Systems
Beam
CCT
Finish

EW1N

D Double Directional

32 2x12W(Max)

COB

2 x 1172

EL ON-OFF

220V AC Power Supply

DL 0-10V Dimming

220V AC Power Supply

1   14°

2   25°

3   35°

A   Away from the wall

T    Towards the wall

30 3000K

40 4000K

WT  White

BK  Black

Model
Comment

Power

(W)

LEDs

(Quantity)

Max Lumens

(lm)

Control Systems
Beam
CCT
Finish

EW1S

D Double Directional

54 2x25(Max)

COB

2 x 2251

EL ON-OFF

220V/AC Power Supply

DL 0-10V Dimming

220V/AC Power Supply

1   16°

2   21°

3   33°

A   Away from the wall

T   Towards the wall

30 3000K

40 4000K

WT  White

BK  Black

Model
Comment

Power

(W)

LEDs

(Quantity)

Max Lumens

(lm)

Control Systems
Beam
CCT
Finish

EW1M

D Double Directional

72 2x32(Max)

COB

2 x 2783

EL ON-OFF

220V/AC Power Supply

DL 0-10V Dimming

220V/AC Power Supply

1  16

2  30°

4  40°

A  Away from the wall

T  Towards the wall

30 3000K

40 4000K

WT  White

BK  Black

Example: EW1MD-72EL-1130WT
