InvisiLED NEON

InvisiLED NEON Vertical

FLSV VERTICAL
Architectural contours come to life with InvisiLED® NEON Vertical. Its precision extrusion process delivers uniform, spot-free light with seamless splicing, ideal for vertical bends and dynamic façade or interior accents.

Specifications

ModelLEDLengthSizeDimmingCCTPower Feed TypeIPFinish

AFLSV

V Curved Neon Strip

06 6W/m

1010W/m

10 1m

20 2m

30 3m

40 4m

50 5m

A  10*10mm

E  ON-OFF(whole stage control)

27 2700K

30 3000K

35 3500K

40 4000K

50 5000K

S cable exit

B cable exit

F cable exit

5 IP65

7 IP67

WT White

ModelLEDLengthSizeDimmingCCTPower Feed TypeIPFinish

AFLSV

V Curved Neon Strip

14 14W/m

18 18W/m


10 1m

20 2m

30 3m

40 4m

50 5m

B  16*16mm

E  ON-OFF(whole stage control)

M  DMX512 8 segments/m

27  2700K

30  3000K

35  3500K

40  4000K

50  5000K

F2  RGBW (2700K)

F3  RGBW (3000K)

F4  RGBW (4000K)

F5   RGBW (5000K)

S cable exit

B cable exit

F cable exit

5 IP65

7 IP67

WT White

ModelLEDLengthSizeDimmingCCTPower Feed TypeIPFinish

AFLSV

V Curved Neon Strip

14 14W/m

18 18W/m


10 1m

20 2m

30 3m

40 4m

50 5m

C  10*20mm

E  ON-OFF(whole stage control)

M  DMX512 8 segments/m


27  2700K

30  3000K

35  3500K

40  4000K

50  5000K

F2  RGBW (2700K)

F3  RGBW (3000K)

F4  RGBW (4000K)

F5   RGBW (5000K)

S cable exit

B cable exit

F cable exit

5 IP65

7 IP67

WT White

Example: AFLSV-0610AE30S5WT

Length is available in 0.1-meter increments. Example model: AFLSV-0615DE30S2WT ("15" denotes 1.5 meters)
