ULTRA
Ultra Square
ASLN36 3" Surface-Mounted Square Downlight
Adaptability defines Ultra Square. Its modular platform allows the reflector and light engine to be exchanged on site, enabling seamless transitions between output levels and beam distributions. Concealed optical technology enhances glare suppression while maintaining color consistency and visual comfort. Designed for hospitality, residential, and commercial interiors, Ultra Square delivers flexible performance within a disciplined architectural form.
Specifications
Model | Size | Trim | LED | Driver | Beam | CCT | Reflector | Finish |
ASLN Surface Mounted N series | 3 3” | 6 Rectangular Trimless | LM08 COB 8W | E On-Off D 0-10V Dimming | S 8° | 27 2700K 30 3000K 35 3500K 40 4000K 50 5000K | B Black S Specular | WT White BK Black |
Model | Size | Trim | LED | Driver | Beam | CCT | Reflector | Finish |
ASLN Surface Mounted N series | 3 3” | 6 Rectangular Trimless | LM07 COB 7W LM10 COB 10W LM13 COB 13W | E On-Off D 0-10V Dimming | N 13° 1 18° 2 28° 3 36° 5 50° | 27 2700K 30 3000K 35 3500K 40 4000K 50 5000K | B Black S Specular | WT White BK Black |
Example: ASLN36-LM07EN30SWT
Note: Factory standard for 8/13/18° is with honeycomb.
